NEXANS and ESCC CROSS REFERENCES

耐克森产品和电气标准协调委员会组件\料号交叉引用对照表

NEXANS P/N 耐克森料号	ESCC COMPONENT/NUMBER电气标准协调委员会组件/号码
BTV1/30/A*	3901.013.78*
BTV1/28/A*	3901.013.01*
BTV1/26/A*	3901.013.02*
BTV1/24/A*	3901.013.03*
BTV1/22/A*	3901.013.04*
BTV1/20/A*	3901.013.05*
BTV1/18/A*	3901.013.56*
BTV1/16/A*	3901.013.57*

BTV2/28/A*	3901.013.06*
BTV2/26/A*	3901.013.07*
BTV2/24/A*	3902.013.08*
BTV2/22/A*	3902.013.09*
BTV2/20/A*	3903.013.10*
BTV2/18/A*	3901.013.58*
BTV2/16/A*	3901.013.59*

BTV3/28/A*	3901.013.11*
BTV3/26/A*	3901.013.12*
BTV3/24/A*	3902.013.13*
BTV3/22/A*	3902.013.14*
BTV3/20/A*	3903.013.15*
BTV3/18/A*	3903.013.60*
BTV3/16/A*	3904.013.61*

BTV4/28/A*	3901.013.16*
BTV4/26/A*	3901.013.17*
BTV4/24/A*	3901.013.18*
BTV4/22/A*	3901.013.19*
BTV4/20/A*	3901.013.19*
BTV4/18/A*	3901.013.62*
BTV4/16/A*	3901.013.63*

BTV2/28/G*	3901.013.21*
BTV2/26/G*	3902.013.22*
BTV2/24/G*	3903.013.23*
BTV2/22/G*	3904.013.24*
BTV2/20/G*	3905.013.25*
BTV2/18/G*	3906.013.64*
BTV2/16/G*	3907.013.65*

BTV3/28/G*	3901.013.26*
BTV3/26/G*	3902.013.27*
BTV3/24/G*	3903.013.28*
BTV3/22/G*	3904.013.29*
BTV3/20/G*	3905.013.30*
BTV3/18/G*	3906.013.66*
BTV3/16/G*	3907.013.67*

BTV4/28/G*	3901.013.31*
BTV4/26/G*	3902.013.32*
BTV4/24/G*	3903.013.33*
BTV4/22/G*	3904.013.34*
BTV4/20/G*	3905.013.35*
BTV4/18/G*	3906.013.68*
BTV4/16/G*	3907.013.68*

BTV1/28/BF/G*	3901.013.36*
BTV1/26/BF/G*	3902.013.37*
BTV1/24/BF/G*	3903.013.38*
BTV1/22/BF/G*	3904.013.39*
BTV1/20/BF/G*	3905.013.40*
BTV1/18/BF/G*	3906.013.70*
BTV1/16/BF/G*	3907.013.71*

BTV2/28/BF/G*	3901.013.41*
BTV2/26/BF/G*	3901.013.42*
BTV2/24/BF/G*	3902.013.43*
BTV2/22/BF/G*	3902.013.44*
BTV2/20/BF/G*	3903.013.45*
BTV2/18/BF/G*	3903.013.72*
BTV2/16/BF/G*	3904.013.73*

BTV3/28/BF/G*	3901.013.46*
BTV3/26/BF/G*	3902.013.47*
BTV3/24/BF/G*	3903.013.48*
BTV3/22/BF/G*	3904.013.49*
BTV3/20/BF/G*	3905.013.50*
BTV3/18/BF/G*	3906.013.74*
BTV3/16/BF/G*	3907.013.75*

BTV4/28/BF/G*	3901.013.51*
BTV4/26/BF/G*	3902.013.52*
BTV4/24/BF/G*	3903.013.53*
BTV4/22/BF/G*	3904.013.54*
BTV4/20/BF/G*	3905.013.55*
BTV4/18/BF/G*	3906.013.76*
BTV4/16/BF/G*	3907.013.77*

*=The reference shall be completed with a letter or a group of letters indicating the control level	*=The reference shall be completed with a letter or a group of letters indicating the control level
NEXANS	ESCC
AQS	B1
AQR	B2
AQ	B3
P	For orders without any reference to ESCC specification.
